10V 1700℃ Vacuum Inert Gas Atmosphere Furnace Nitrogen Argon Box Vacuum Atmosphere Furnace 0-20℃/min

Specification Voltage: AC110V Power: 4kW Heating chamber size: 5.9"*5.9"*5.9"(15cm*15cm*15cm) Max. temperature: 1700℃ Working temperature: 1600℃ Heating rate: 0-20℃/min Temperature accuracy: ±1℃ Heating element: MoSi2 heater Thermocouple: Type B Furnace door material: Double-layer thickened steel plate Furnace body material: Premium carbon steel Furnace material: Alumina polycrystalline fiber Package Dimensions 30"*28"*55";574pounds

• [Control Panel] The control panel integrates a temperature controller, ammeter, voltmeter, power switch, indicators, and an intelligent LCD display for clear data and easy operation. The furnace adopts modular integrated circuit control with dual-loop protection (over-temperature, deviation, overcurrent, overvoltage, circuit break protection), ensuring stable and safe operation.
• [Gas Control System] Equipped with a vacuum pressure gauge for real-time monitoring of the furnace chamber vacuum level, this unit also integrates a float-type flow meter for intuitive adjustment of gas flow rates. The inlet and outlet valves support multi-gas switching, including hydrogen (<5%), argon, nitrogen, etc., ensuring safe gas replacement during high-temperature operation.
• [Furnace Material] The furnace adopts advanced lightweight alumina polycrystalline fiber, delivering exceptional thermal insulation, high-temperature resistance, and rapid thermal cycling performance. This material ensures zero contamination to the processed products, while achieving energy savings of 60%–80% compared with conventional electric furnaces.
• [Furnace Door Design] The furnace door features a double-layer thickened steel plate design, effectively isolating heat and keeping the surface temperature safe during operation. It is equipped with four handwheel locking mechanisms for stable pressure during vacuum or gas charging, preventing furnace shell deformation.
• [Vacuum Sealing Performance] The furnace door has an integrally milled flat surface with embedded silicone seals, ensuring excellent sealing and stable atmosphere control. Its user-friendly design combines industrial-grade sealing with lab operation convenience.
