YANHAO 6IN1 Din Rail AC Volt Monitor 110V 220V 380V Current Power Kwh Electric Energy Meter AMP 100A D52-2066 1Pcs (Color : Built-in CT, Size : 40-300V)

Instrumentation>>DescriptionD52-2066 guide rail type digital display multi-function meter simultaneously displays 6 parameters such as AC voltage, AC current, active power, power factor, frequency and electric energy on the instrument. The meter uses a color full-view high-definition LCD display to display the measurement results.>>SpecificationMeasurement Accuracy: 1%±2 wordsMeasuring Range:AC voltage AC 40-300V (110V 220V use), AC 200-450V (380V 450V use)Alternating Current: AC 0-100V, current display resolution is 0.01APower Frequency: 45Hz-65HzPower Fator:0.00-1.00PFActive Power: the measurement range is 0-45000W, the display resolution between 0-9999.9W is 0.1W, and the rest is 1 WElectricity: The measurement range is 0-99999kwh, The minimum display resolution of 0-999.99kwh is 0.01kwh 1000.0-9999.9kwh minimum display resolution is 0.1kwh. The minimum resolution of 10000.0-99999kwh is 1kwhMeasuring Speed: About 2 times per secondDimensions: 54*80*64mmInstallation Method: Rail Type>>Package Included1 × D52-2066 Multi-Function Instrument>>NoteThe measuring voltage range of this instrument is 200-450V and only applicable to the city power supply of pure AC 45-65Hz, and the measuring range is 40-300V.Please pay attention to purchaseTo measure 110V 220V voltage, please check AC40-300V, and measure 380V voltage to check 200-450V!If 200-450V is used to measure the voltage of 220V, the meter measurement is inaccurate, please pay attention!To measure the ABC three-phase voltage at the same time, AC40-300V must be used, and the premise equipment must have a neutral line, and three pieces need to be purchased! If you buy AC200-450V, only one of the three phases can be measured.
