100S 100Hz/1Khz/10Khz Mini Intelligent Bridge Tweezers Tester Resistance Capacitance Inductance Diode Tester,1 * Mini Intelligent Bridge Tweezers,Black

Test parameters: L, C, R, D, Q, ESRD/0/Z/φ<br>Diode test: Supported<br>Basic accuracy: 0.5%<br>Equivalent circuit: series/parallel<br>Range mode: Automatic<br>Test speed: 2 times/s<br>Test segment configuration: Kelvin test<br>Display: 1.14-inch color screen, resolution 240 * 135<br>Power display: Supported<br>Battery capacity: 300mA<br>Battery life: 5 hours<br> frequency: 100hZ/1KHz/10kHz<br> level: 0.6V/0.3V/0.1V RMS<br>Measurement range:<br>R: 0.01Ω-20.00MΩ<br>C: 0.01pF-999.9mF<br>L: 0.1μH-9999H<br>D,Q:0.001-9999<br>Due to different batches, there may be differences in product appearance, color, and printed text, which not affect the use.<br>Color: black<br>Material: plastic<br><br>Package Contents:<br>1 * Mini Intelligent Bridge Tweezers<br><br>Only the above package content, other products are not included.<br>Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.

• 1. High- measurement: The basic accuracy reaches 0.5%, ensuring the reliability and accuracy of the measurement results.
• 5. Automatic range selection: The device automatically selects the measurement range, simplifies the operation process, improves test efficiency, and is suitable for various measurement scenarios.
• 2. Multi-function test: Supports the test of multiple parameters such as L (inductance), C (capacitance), R (resistance), D (diode), Q (quality factor), etc., to meet the test needs of different electronic components.
• 3. Fast test speed: 2 times/second test speed, improve work efficiency, suitable for fast-paced working environment.
• 4. Long-lasting battery: 300mA battery capacity, supports 5 hours of continuous use, suitable for long-term outdoor or field testing work.
